Image 1 of 1
Best Features of Optidrive Eco
✔ Energy Saving Auto PID
✔ Sleep / Wake Mode
✔ Multi Pump Cascade Control
✔ Fire Mode
✔ BACnet Standard
✔ Quiet Motor Operation
✔ Sensorless Vector Control
Industries served by Optidrive Eco
Need and Recommended Model Type
Small Water Pump: 0.75–2.2kW IP66
AHU / HVAC Fan: 4–15kW IP20
Booster Pump System: 18.5–37kW IP55
Outdoor Cooling Tower: IP66 Series
Heavy Industrial Pump: 75–250kW IP55
Optidrive E3 Model Configuration
| Input Voltage | kW | HP | Amps | Frame | Model Code Structure |
|---|---|---|---|---|---|
| 110-115V ±10% 1 Phase Input |
0.37 | 0.5 | 2.3 | 1 | ODE - 3 - 1 1 0023 - 1 0 1 # |
| 0.75 | 1 | 4.3 | 1 | ODE - 3 - 1 1 0043 - 1 0 1 # | |
| 1.1 | 1.5 | 5.8 | 2 | ODE - 3 - 2 1 0058 - 1 0 4 # | |
| 200-240V ±10% 1 Phase Input |
0.37 | 0.5 | 2.3 | 1 | ODE - 3 - 1 2 0023 - 1 # 1 # |
| 0.75 | 1 | 4.3 | 1 | ODE - 3 - 1 2 0043 - 1 # 1 # | |
| 1.5 | 2 | 7 | 1 | ODE - 3 - 1 2 0070 - 1 # 1 # | |
| 1.5 | 2 | 7 | 2 | ODE - 3 - 2 2 0070 - 1 # 4 # | |
| 2.2 | 3 | 10.5 | 2 | ODE - 3 - 2 2 0105 - 1 # 4 # | |
| 4 | 5 | 15.3 | 3 | ODE - 3 - 3 2 0153 - 1 0 4 # | |
| 380-480V ±10% 3 Phase Input (Partial List) |
0.75 | 1 | 2.2 | 1 | ODE - 3 - 1 4 0022 - 3 # 1 # |
| 1.5 | 2 | 4.1 | 1 | ODE - 3 - 1 4 0041 - 3 # 1 # | |
| 2.2 | 3 | 5.8 | 2 | ODE - 3 - 2 4 0058 - 3 # 4 # | |
| 11 | 15 | 24 | 3 | ODE - 3 - 3 4 0240 - 3 # 4 # | |
| 37 | 50 | 72 | 5 | ODE - 3 - 5 4 0720 - 3 F 4 2 |
Physical Dimensions
IP20 Enclosure
| Size | 1 | 2 | 3 | 4 | 5 |
|---|---|---|---|---|---|
| Height (mm) | 173 | 221 | 261 | 420 | 486 |
| Width (mm) | 83 | 110 | 131 | 171 | 222 |
| Depth (mm) | 123 | 150 | 175 | 212 | 226 |
| Weight (kg) | 1.0 | 1.7 | 3.2 | 9.1 | 18.1 |
IP66 Enclosure
| Size | 1 | 2 | 3 | 4 |
|---|---|---|---|---|
| Height (mm) | 232 | 257 | 310 | 360 |
| Width (mm) | 161 | 188 | 211 | 240 |
| Depth (mm) | 162 | 182 | 235 | 271 |
| Weight (kg) | 2.3 | 3.5 | 6.6 | 9.5 |
